| Type |
Power Chip |
| Technology |
Wirewound |
| Protection Style |
Unshielded |
| Core Material |
Ferrite |
| Inductance (H) |
10u |
| Tolerance |
10% |
| Inductance Test Frequency (Hz) |
1M |
| Maximum DC Current (A) |
0.3 |
| Typical Temperature Rise (°C) |
20 |
| Maximum Saturation Current (A) |
0.3 |
| Inductance Decrease Percentage @ Isat (%) |
10 |
| Maximum DC Resistance (Ohm) |
0.572 |
| Minimum Self Resonant Frequency (Hz) |
26M |
| Maximum Operating Temperature (°C) |
85 |
| Minimum Operating Temperature (°C) |
-40 |
| Operating Temperature (°C) |
-40 to 85 |
| Polarity |
No |
| Maximum Terminal Width (mm) |
1.2 |
| Maximum Storage Temperature (°C) |
85 |
| Minimum Storage Temperature (°C) |
-40 |
