| Type |
RF Chip |
| Technology |
Multi-Layer |
| Protection Style |
Shielded |
| Core Material |
Ferrite |
| Inductance (H) |
4.7u |
| Tolerance |
10% |
| Inductance Test Frequency (Hz) |
10M |
| Maximum DC Current (A) |
0.03 |
| Typical Temperature Rise (°C) |
25 |
| Maximum Saturation Current (A) |
0.03 |
| Inductance Decrease Percentage @ Isat (%) |
5 |
| Maximum DC Resistance (Ohm) |
1 |
| Minimum Quality Factor |
45 |
| Quality Test Frequency (Hz) |
10M |
| Minimum Self Resonant Frequency (Hz) |
47M |
| Maximum Operating Temperature (°C) |
85 |
| Minimum Operating Temperature (°C) |
-40 |
| Operating Temperature (°C) |
-40 to 85 |
| Polarity |
No |
| Maximum Terminal Width (mm) |
0.8 |
| Maximum Storage Temperature (°C) |
125 |
| Minimum Storage Temperature (°C) |
-55 |
