| Manufacturer Type |
High Speed Amplifier |
| Type |
High Speed Amplifier |
| Number of Channels per Chip |
1 |
| Process Technology |
Bipolar |
| Minimum PSRR (dB) |
92 |
| Typical Gain Bandwidth Product (MHz) |
22 |
| Minimum Dual Supply Voltage (V) |
±2.5 |
| Maximum Input Offset Voltage (mV) |
0.6@±5V |
| Typical Dual Supply Voltage (V) |
±3|±5|±9|±12|±15 |
| Maximum Dual Supply Voltage (V) |
±18 |
| Maximum Input Offset Current (uA) |
0.12@±15V |
| Maximum Input Bias Current (uA) |
0.5@±15V |
| Maximum Operating Supply Voltage (V) |
±18 |
| Maximum Supply Voltage Range (V) |
36 to 37 |
| Minimum CMRR (dB) |
78 |
| Minimum CMRR Range (dB) |
75 to 80 |
| Typical Voltage Gain (dB) |
93.06 |
| Typical Slew Rate (V/us) |
220@±5V |
| Typical Settling Time (ns) |
380 |
| Typical Output Current (mA) |
25@±5V |
| Typical Input Noise Voltage Density (nV/rtHz) |
8@±15V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.8@±15V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Commercial |
| Power Supply Type |
Dual |
| Maximum Supply Current (mA) |
2.4@±5V |
| Maximum Power Dissipation (mW) |
387 |
