| Manufacturer Type |
Precision Amplifier |
| Type |
Precision Amplifier |
| Rail to Rail |
Rail to Rail Output |
| Number of Channels per Chip |
1 |
| Minimum Single Supply Voltage (V) |
2.4 |
| Process Technology |
BiCMOS |
| Minimum PSRR (dB) |
97 |
| Typical Single Supply Voltage (V) |
3|5 |
| Output Type |
CMOS |
| Maximum Single Supply Voltage (V) |
5.5 |
| Typical Gain Bandwidth Product (MHz) |
1.7 |
| Maximum Quiescent Current (mA) |
0.35(Typ)@5V |
| Maximum Input Offset Voltage (mV) |
0.05@5V |
| Maximum Input Offset Current (uA) |
0.000001(Typ)@5V |
| Maximum Input Bias Current (uA) |
0.0005@5.5V@-40C to 85C |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Maximum Supply Voltage Range (V) |
5.5 to 6 |
| Minimum CMRR (dB) |
82 |
| Minimum CMRR Range (dB) |
80 to 85 |
| Typical Voltage Gain (dB) |
128 |
| Typical Slew Rate (V/us) |
0.3@5V |
| Typical Settling Time (ns) |
1000 |
| Typical Output Current (mA) |
20(Max) |
| Typical Input Noise Voltage Density (nV/rtHz) |
14@5.5V |
| Typical Input Bias Current (uA) |
0.000001@5V |
| Shut Down Support |
Yes |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Extended |
| Power Supply Type |
Single |
| Maximum Power Dissipation (mW) |
696 |
