| Type |
Analog Switch |
| Number of Channels per Chip |
4 |
| Switch Architecture |
SPST |
| Polarity |
Non-Inverting |
| Maximum On Resistance Range (Ohm) |
400 to 1000 |
| Configuration |
Quad SPST |
| Number of Inputs per Chip |
4 |
| Function |
General |
| Number of Outputs per Chip |
4 |
| Chip Enable Signals |
Yes |
| Maximum On Resistance (Ohm) |
500@2.7V |
| Maximum Turn-On Time (ns) |
250@2.7V |
| Maximum Turn-Off Time (ns) |
80@2.7V |
| Maximum Power Dissipation (mW) |
696 |
| Input Signal Type |
Single |
| Output Signal Type |
Single |
| Maximum Low Level Output Current (mA) |
10 |
| Maximum High Level Output Current (mA) |
10 |
| Switch Control Logic |
Active Low |
| Switch Normal Position |
NC |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Extended |
| Power Supply Type |
Single|Dual |
| Minimum Single Supply Voltage (V) |
2 |
| Typical Single Supply Voltage (V) |
3|5|9 |
| Maximum Single Supply Voltage (V) |
12 |
| Minimum Dual Supply Voltage (V) |
±2 |
| Typical Dual Supply Voltage (V) |
±3|±5 |
| Maximum Dual Supply Voltage (V) |
±6 |
| Typical Supply Current (mA) |
0.00005@5.5V |
| Maximum Supply Current (mA) |
0.001@5.5V |
