| type |
Schottky Diode |
| Configuration |
Single |
| Peak Reverse Repetitive Voltage (V) |
40 |
| Maximum DC Reverse Voltage (V) |
40 |
| Maximum Continuous Forward Current (A) |
0.5 |
| Maximum Junction Ambient Thermal Resistance |
206°C/W |
| Peak Forward Voltage (V) |
0.62@1A |
| Peak Non-Repetitive Surge Current (A) |
5.5 |
| Peak Reverse Current (uA) |
20 |
| Operating Junction Temperature (°C) |
-55 to 150 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
150 |
