| Manufacturer Type |
General Purpose Amplifier |
| Type |
General Purpose Amplifier |
| Number of Channels per Chip |
4 |
| Minimum Single Supply Voltage (V) |
4 |
| Process Technology |
Bipolar |
| Typical Single Supply Voltage (V) |
5|9|12|15|18|24|28 |
| Maximum Single Supply Voltage (V) |
44 |
| Typical Gain Bandwidth Product (MHz) |
2.1 |
| Minimum Dual Supply Voltage (V) |
±2 |
| Maximum Quiescent Current (mA) |
0.25@5V |
| Maximum Input Offset Voltage (mV) |
5@5V |
| Typical Dual Supply Voltage (V) |
±3|±5|±9|±12|±15|±18 |
| Maximum Dual Supply Voltage (V) |
±22 |
| Maximum Input Offset Current (uA) |
0.02@±15V |
| Maximum Input Bias Current (uA) |
0.1@±15V |
| Maximum Operating Supply Voltage (V) |
±22|44 |
| Maximum Supply Voltage Range (V) |
>=44 |
| Minimum CMRR (dB) |
80 |
| Minimum CMRR Range (dB) |
80 to 85 |
| Typical Voltage Gain (dB) |
100 |
| Typical Slew Rate (V/us) |
2@±15V |
| Typical Input Noise Voltage Density (nV/rtHz) |
29@±15V |
| Typical Input Bias Current (uA) |
0.02@±15V@-40C to 105C |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
105 |
| Power Supply Type |
Single|Dual |
