| Manufacturer Type |
Low Power Amplifier |
| Type |
Low Power Amplifier |
| Rail to Rail |
Rail to Rail Output |
| Minimum Single Supply Voltage (V) |
2.7 |
| Number of Channels per Chip |
1 |
| Process Technology |
CMOS |
| Minimum PSRR (dB) |
80 |
| Typical Single Supply Voltage (V) |
3|5 |
| Maximum Single Supply Voltage (V) |
6 |
| Output Type |
CMOS |
| Maximum Quiescent Current (mA) |
0.325@5.5V |
| Typical Gain Bandwidth Product (MHz) |
2.8 |
| Maximum Input Offset Voltage (mV) |
2@5.5V |
| Maximum Input Offset Current (uA) |
0.000001(Typ)@5.5V |
| Maximum Operating Supply Voltage (V) |
6 |
| Maximum Input Bias Current (uA) |
0.00006@5.5V@85C |
| Minimum CMRR (dB) |
75 |
| Maximum Supply Voltage Range (V) |
6 to 9 |
| Minimum CMRR Range (dB) |
75 to 80 |
| Typical Voltage Gain (dB) |
115 |
| Typical Slew Rate (V/us) |
2.3@5.5V |
| Typical Settling Time (ns) |
4500 |
| Typical Output Current (mA) |
30(Max) |
| Typical Input Noise Voltage Density (nV/rtHz) |
29@5.5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.0006@5.5V |
| Typical Input Bias Current (uA) |
0.000001@5.5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Industrial |
| Power Supply Type |
Single |
