| Manufacturer Type |
General Purpose Amplifier |
| Type |
General Purpose Amplifier |
| Rail to Rail |
Rail to Rail Input/Output |
| Minimum Single Supply Voltage (V) |
2.5 |
| Number of Channels per Chip |
2 |
| Process Technology |
CMOS |
| Minimum PSRR (dB) |
74 |
| Typical Single Supply Voltage (V) |
3|5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Output Type |
CMOS |
| Maximum Quiescent Current (mA) |
2.7@5.5V |
| Typical Gain Bandwidth Product (MHz) |
10 |
| Maximum Input Offset Voltage (mV) |
0.25@5V |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Maximum Input Bias Current (uA) |
0.005@5.5V@125C |
| Minimum CMRR (dB) |
70 |
| Maximum Supply Voltage Range (V) |
5.5 to 6 |
| Minimum CMRR Range (dB) |
70 to 71 |
| Typical Voltage Gain (dB) |
110 |
| Typical Slew Rate (V/us) |
7@5.5V |
| Typical Settling Time (ns) |
250 |
| Typical Output Current (mA) |
30(Max) |
| Typical Input Noise Voltage Density (nV/rtHz) |
8.7@5.5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.003@5.5V |
| Typical Input Bias Current (uA) |
0.000001@5.5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Extended |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single |
