| Manufacturer Type |
Driver Amplifier |
| Number of Channels per Chip |
1 |
| Typical Power Gain (dB) |
20@1500MHz |
| Typical Noise Figure (dB) |
1.8@1500MHz |
| Operational Bias Conditions |
5V/111mA |
| Typical Output 1dB Compressed Power @ Bias Conditions (dBm) |
24.4 |
| Typical 3rd Order Output Intercept Point @ Bias Conditions (dBm) |
41.3 |
| Typical Gain Flatness (dB) |
0.1 |
| Typical Output Intercept Point (dBm) |
41.3@1500MHz |
| Maximum Reverse Isolation (dB) |
27.5(Typ)@1500MHz |
| Minimum Operating Frequency (MHz) |
50 |
| Maximum Power Dissipation (mW) |
825 |
| Maximum Operating Frequency (MHz) |
2000 |
| Typical Output Power (dBm) |
24.4@1500MHz |
| Typical Output Power Range (dBm) |
20 to 30 |
| Maximum Input Return Loss (dB) |
15.9(Typ)@1500MHz |
| Maximum Output Return Loss (dB) |
16(Typ)@1500MHz |
| Power Supply Type |
Single |
| Typical Single Supply Voltage (V) |
5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Maximum Operating Temperature (°C) |
150 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
