| Type |
LDO |
| Number of Outputs |
1 |
| Maximum Output Current (A) |
0.25 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Output Type |
Fixed |
| Output Voltage Range (V) |
1.8 to 10 |
| Junction to Case |
15°C/W |
| Polarity |
Positive |
| Special Features |
Current Limit|Shutdown|Thermal Protection |
| Load Regulation |
0.2%/V |
| Line Regulation |
0.1%/V |
| Maximum Quiescent Current (mA) |
0.2 |
| Maximum Dropout Voltage @ Current (V) |
0.1@1mA|0.25@50mA|0.3@100mA|0.45@250mA |
| Minimum Input Voltage (V) |
2 |
| Maximum Input Voltage (V) |
30 |
| Output Voltage (V) |
5 |
| Typical Quiescent Current (mA) |
0.14 |
| Typical Dropout Voltage @ Current (V) |
0.06@1mA|0.22@50mA|0.25@100mA|0.375@250mA |
| Reference Voltage (V) |
1.25 |
| Accuracy (%) |
±0.5 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Typical Ground Current @ Full Load (mA) |
5 |
| Typical Output Noise Voltage (uVrms) |
400 |
