| Type |
NPN |
| Configuration |
Single |
| Maximum Collector-Emitter Voltage (V) |
100 |
| Maximum Collector Base Voltage (V) |
100 |
| Maximum DC Current Gain |
12000@2A@3V |
| Maximum Emitter Base Voltage (V) |
5 |
| Maximum Continuous DC Collector Current (A) |
2 |
| Maximum Power Dissipation (mW) |
1750 |
| Minimum Transition Frequency (MHz) |
25 |
| Output Clamp Diode |
Yes |
| Maximum Base Current (A) |
0.05 |
| Operating Junction Temperature (°C) |
-65 to 150 |
| Maximum Base Emitter Saturation Voltage (V) |
4@40mA@4A |
| Maximum Collector Cut-Off Current (uA) |
20 |
| Maximum Collector-Emitter Saturation Voltage (V) |
2@8mA@2A|3@40mA@4A |
| Maximum Collector-Emitter Cut-Off Current (mA) |
0.02 |
| Typical Current Gain Bandwidth (MHz) |
25(Min) |
| Minimum DC Current Gain |
500@0.5A@3V|1000@2A@3V|200@4A@3V |
| Minimum DC Current Gain Range |
<500|500 to 3600 |
| Number of Elements per Chip |
1 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-65 |
| Maximum Operating Temperature (°C) |
150 |
