MJD45H11T4G onsemi TRANS PNP 80V 8A DPAK

2024/08/1 182

• Lead Formed for Surface Mount Application in Plastic Sleeves (No Suffix)

• Straight Lead Version in Plastic Sleeves (“−1” Suffix)

• Electrically Similar to Popular D44H/D45H Series

• Low Collector Emitter Saturation Voltage

• Fast Switching Speeds

• Complementary Pairs Simplifies Designs

• Epoxy Meets UL 94 V−0 @ 0.125 in

• NJV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant

CATALOG

Malaysia

China

Viet Nam

Type	PNP
Configuration	Single
Maximum Collector-Emitter Voltage (V)	80
Maximum Emitter Base Voltage (V)	5
Maximum Pulsed Collector Current (A)	16
Maximum DC Collector Current (A)	8
Typical Transition Frequency (MHz)	90
Material	Si
Maximum Power Dissipation (mW)	1750
Collector Current for VCE Saturation (mA)	8000
Maximum Emitter Cut-Off Current (nA)	1000
Maximum Junction Ambient Thermal Resistance	71.4°C/W
Maximum Junction Case Thermal Resistance	6.25°C/W
Typical Output Capacitance (pF)	130
Operating Junction Temperature (°C)	-55 to 150
Maximum Storage Time (ns)	500(Typ)
Maximum Fall Time (ns)	100(Typ)
Maximum Collector-Emitter Saturation Voltage (V)	1@0.4A@8A
Maximum Base Emitter Saturation Voltage (V)	1.5@0.8A@8A
Category	Bipolar Power
Minimum DC Current Gain	60@2A@1V\|40@4A@1V
Number of Elements per Chip	1
Minimum Storage Temperature (°C)	-55
Maximum Storage Temperature (°C)	150
Minimum Operating Temperature (°C)	-55
Maximum Operating Temperature (°C)	150

MSL	1
Maximum Reflow Temperature (°C)	260
Reflow Solder Time (Sec)	30
Number of Reflow Cycle	3
Standard	IPC-1752
Reflow Temp. Source	Link to Datasheet
Maximum Wave Temperature (°C)	N/R
Wave Solder Time (Sec)	N/R
Lead Finish(Plating)	Matte Sn annealed
Under Plating Material	N/A
Terminal Base Material	Cu Alloy
Number of Wave Cycles	N/R
