• Wide 5V to 60V Input Voltage Range
|
• Bootstrap Gate Driver with Trickle-Charge Circuit Supports 100% Duty Cycle Operation
|
• Low-Power Sleep Mode for BatteryPowered Applicat
|
• Programmable Over-Current Protection of the External MOSFETs
|
• Adjustable Dead-Time Control to Prevent Shoot-Through
|
|
| CATALOG |
MP6531AGR-P Country of Origin
|
MP6531AGR-P Package Info
|
MP6531AGR-P APPLICATIONS
|
|
COUNTRY OF ORIGIN
|
China
|
Taiwan (Province of China)
|
|
PACKAGE INFO
|
| Supplier Package |
QFN EP |
| Pin Count |
28 |
| Lead Shape |
No Lead |
| PCB |
28 |
| Tab |
N/R |
| Package Length (mm) |
4.1(Max) |
| Package Width (mm) |
4.1(Max) |
| Package Height (mm) |
0.95(Max) |
| Package Diameter (mm) |
N/R |
| Mounting |
Surface Mount |
| Package Description |
Quad Flat No Lead Package, Exposed Pad |
| Package Family Name |
QFN |
| Package Outline |
Link to Datasheet |
|
|
APPLICATIONS
|
• Three-Phase, Brushless, DC Motors
|
• Permanent Magnet Synchronous Motors
|
• Power Drills
|
| • Impact Drivers |
| • E-Bikes |
| |
