| Family Name |
PowerQUICC II Pro MPC83xx Processor |
| Data Bus Width (bit) |
32 |
| Device Core |
e300 |
| Maximum Speed (MHz) |
533 |
| Instruction Set Architecture |
RISC |
| Number of CPU Cores |
1 |
| Data Cache Size |
32KB |
| Instruction Cache Size |
32KB |
| Ethernet Interface Type |
GMII/MII/RGMII/RMII |
| Interface Type |
Ethernet/I2C/SPI/UART/USB |
| Ethernet Speed |
10Mbps/100Mbps/1000Mbps |
| Multiply Accumulate |
No |
| I/O Voltage (V) |
1.8|2.5|3.3 |
| Maximum Power Dissipation (mW) |
5300 |
| CAN |
0 |
| Ethernet |
2 |
| I2C |
2 |
| I2S |
0 |
| SPI |
2 |
| UART |
2 |
| USART |
0 |
| USB |
1 |
| Programmability |
Yes |
| Minimum Operating Supply Voltage (V) |
1.14 |
| Typical Operating Supply Voltage (V) |
1.2 |
| Maximum Operating Supply Voltage (V) |
1.26 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
105 |
| Temperature Flag |
Jun |
| Operating Supply Voltage (V) |
1.2 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-55 |
