| Technology |
IEEE 802.11b/g |
| Modulation Technique |
DSSS|OFDM |
| Number of Channels |
11 |
| Minimum Operating Frequency (MHz) |
2405 |
| Maximum Operating Frequency (MHz) |
2480 |
| Maximum Data Rate (Kbps) |
11000@b|54000@g |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Industrial |
| Band Mode |
Single Mode |
| Maximum Current Consumption (RX) (mA) |
156(Typ) |
| Maximum Current Consumption (TX) (mA) |
240 |
| Minimum Operating Supply Voltage (V) |
2.8 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Interface |
4-Wire/SPI |
| ISM Band |
2.4GHz |
| Maximum Output Power |
18dBm(Typ) |
| Security |
AES/WEP/WPA-PSK/WPA2-PSK |
| Typical Sensitivity |
-95dBm@1Mbps |
| Solutions |
ISM/M2M/SRD |
| Style |
Board |
| Wi-Fi Compliant |
No |
| Minimum Storage Temperature (°C) |
-40 |
| Maximum Storage Temperature (°C) |
125 |
| Antenna Mounting |
On Board |
| Processing Unit Type |
Microcontroller |
| Operation Mode |
Ad-Hoc|Client|Infrastructure |
| Wi-Fi Direct |
Yes |
