MS27484E22B55P COUNTRY OF ORIGIN
|
MS27484E22B55P PARAMETRIC INFO
|
MS27484E22B55P PACKAGE INFO
|
MS27484E22B55P MANUFACTURING INFO
|
|
COUNTRY OF ORIGIN
|
China
|
|
PARAMETRIC INFO
|
| Type |
Circular |
| Contact Gender |
PIN |
| Number of Contacts |
55 |
| Termination Method |
Crimp |
| Number of Ports |
1 |
| Gender |
PL |
| Contacts Classification |
55Signal |
| Shell Size / Insert Arrangement |
22-55 |
| Mating Style |
Bayonet Lock |
| Maximum Voltage Rating |
850VDC|600VAC |
| Wire Size (AWG) |
20-24 |
| Military Standard Series |
Series II |
| Shell Material |
Aluminum Alloy |
| Housing Color |
Olive Drab |
| Shell Plating |
Cadmium |
| Contact Material |
Copper Alloy |
| Contact Plating |
Gold |
| Strain Relief |
No |
| Polarization |
N |
| Less Contact |
No |
| Operating Temperature (°C) |
-65 to 175 |
| Minimum Operating Temperature (°C) |
-65 |
| Maximum Operating Temperature (°C) |
175 |
| Mating Cycle (Cycles) |
500 |
|
|
PACKAGE INFO
|
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Number of Terminals |
55 |
| Product Length (mm) |
23.82 |
| Product Depth (mm) |
N/R |
| Product Height (mm) |
N/R |
| Product Diameter (mm) |
41.27 |
|
|
