| Density (bit) |
256M |
| Cell Type |
NOR |
| Interface Type |
Serial (SPI, Dual SPI, Quad SPI) |
| Block Organization |
Symmetrical |
| Boot Block |
No |
| Timing Type |
Synchronous |
| Architecture |
Sectored |
| Maximum Access Time (ns) |
8 |
| Programmability |
Yes |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Cycle Time (s) |
40m |
| Tradename |
MXSMIO® |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Industrial |
| Number of Bits per Word (bit) |
1/2/4 |
| Number of Words |
256M/128M/64M |
| Maximum Operating Current (mA) |
30 |
| Programming Voltage (V) |
2.7 to 3.6 |
| Maximum Operating Frequency (MHz) |
120 |
| Sector Size |
4Kbyte x 8192 |
| Program Current (mA) |
25 |
| Address Width (bit) |
32 |
| Minimum Operating Supply Voltage (V) |
2.7 |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Maximum Erase Time (s) |
150/Chip |
| Maximum Programming Time (ms) |
0.75/Page |
| Command Compatible |
Yes |
| ECC Support |
No |
| Erase Suspend/Resume Modes Support |
Yes |
| Simultaneous Read/Write Support |
No |
| Support of Common Flash Interface |
No |
| Support of Page Mode |
No |
| Page Size |
256byte |
| Minimum Endurance (Cycles) |
100000(Typ) |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Density in Bits (bit) |
268435456 |
| Process Technology |
CMOS |
