NHD-0420H1Z-FL-GBW-33V3 COUNTRY OF ORIGIN
|
NHD-0420H1Z-FL-GBW-33V3 PARAMETRIC INFO
|
NHD-0420H1Z-FL-GBW-33V3 PACKAGE INFO
|
NHD-0420H1Z-FL-GBW-33V3 PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
China
|
|
PARAMETRIC INFO
|
| LCD Type |
STN |
| Character Format |
20Char x 4Line |
| Backlight |
LED |
| Display Mode |
Transflective |
| Typical Response Time (ms) |
240 |
| Typical Contrast Ratio |
2 |
| Minimum Operating Temperature (°C) |
-20 |
| Maximum Operating Temperature (°C) |
70 |
| Minimum Storage Temperature (°C) |
-30 |
| Maximum Storage Temperature (°C) |
80 |
|
|
PACKAGE INFO
|
| Supplier Package |
N/A |
| Basic Package Type |
N/A |
| Pin Count |
16 |
| PCB |
16 |
| Tab |
N/R |
| Package Length (mm) |
79 |
| Package Width (mm) |
36 |
| Package Height (mm) |
13(Max) |
| Package Diameter (mm) |
N/R |
| Mounting |
Screw |
| Package Weight (g) |
N/A |
| Package Family Name |
N/A |
| Package Outline |
Link to Datasheet |
|
|
PACKAGING INFO
|
| Packaging Document |
Link to Datasheet |
|
|
