• 4.8 m x 4.8 m Low Noise Global Shutter Pixels with In-pixel CDS
|
• Monochrome (SN), Color (SE) and NIR (FN)
|
• Zero Row Overhead Time (ZROT) Mode Enabling Higher Frame Rate
|
• On−chip 10−bit Analog−to−Digital Converter (ADC)
|
• Four/Two/One LVDS High Speed Serial Outputs or Parallel CMOS Output
|
• Random Programmable Region of Interest (ROI) Readout
|
• Serial Peripheral Interface (SPI)
|
• Automatic Exposure Control (AEC)
|
|
| CATALOG |
NOIP1SN1300A-QTI COUNTRY OF ORIGIN
|
NOIP1SN1300A-QTI PARAMETRIC INFO
|
NOIP1SN1300A-QTI PACKAGE INFO
|
NOIP1SN1300A-QTI PACKAGING INFO
|
NOIP1SN1300A-QTI APPLICATIONS
|
|
COUNTRY OF ORIGIN
|
Thailand
|
United States of America
|
|
PARAMETRIC INFO
|
| Type |
CMOS |
| Color Sensing |
Monochrome |
| Pixel Size (um) |
4.8x4.8 |
| Image Size (Pixels) |
1280x1024 |
| Minimum Operating Supply Voltage (V) |
1.7|3.2 |
| Typical Operating Supply Voltage (V) |
1.8|3.3 |
| Maximum Operating Supply Voltage (V) |
1.9|3.4 |
| Maximum Clock Frequency (MHz) |
72 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Image Size Range (Pixels) |
>= 480,000 |
| Operating Supply Voltage (V) |
1.7 to 1.9|3.2 to 3.4 |
| Minimum Storage Temperature (°C) |
-40 |
| Maximum Storage Temperature (°C) |
150 |
|
|
PACKAGE INFO
|
| Supplier Package |
LLCC |
| Pin Count |
48 |
| PCB |
48 |
| Tab |
N/R |
| Package Length (mm) |
14.35(Max) |
| Package Width (mm) |
14.35(Max) |
| Package Height (mm) |
2.55(Max) |
| Package Diameter (mm) |
N/R |
| Mounting |
Surface Mount |
| Package Material |
Plastic |
| Package Description |
Leadless Ceramic Carrier |
| Package Family Name |
LCC |
| Package Outline |
Link to Datasheet |
|
|
PACKAGING INFO
|
| Packaging |
Tray |
| Quantity Of Packaging |
64 |
|
|
| APPLICATIONS |
• Machine Vision
|
• Motion Monitoring
|
• Security
|
• Barcode Scanning (2D)
|
|
