| Manufacturer Type |
Ultra Low Offset Voltage Amplifier |
| Type |
Ultra Low Offset Voltage Amplifier |
| Number of Channels per Chip |
1 |
| Minimum PSRR (dB) |
123.1(Typ) |
| Typical Gain Bandwidth Product (MHz) |
0.6 |
| Minimum Dual Supply Voltage (V) |
±3 |
| Typical Dual Supply Voltage (V) |
±5|±9|±12|±15|±18 |
| Maximum Input Offset Voltage (mV) |
0.06@±15V |
| Maximum Dual Supply Voltage (V) |
±22 |
| Maximum Input Offset Current (uA) |
0.0028@±15V |
| Maximum Input Bias Current (uA) |
0.0028@±15V |
| Maximum Operating Supply Voltage (V) |
±22 |
| Maximum Supply Voltage Range (V) |
>=44 |
| Minimum CMRR (dB) |
140(Typ) |
| Minimum CMRR Range (dB) |
>=115 |
| Typical Voltage Gain (dB) |
135.56 |
| Typical Slew Rate (V/us) |
0.3@±15V |
| Typical Input Noise Voltage Density (nV/rtHz) |
10.5@±15V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-25 |
| Maximum Operating Temperature (°C) |
85 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Dual |
