| Manufacturer Type |
Low Power Amplifier |
| Type |
Low Power Amplifier |
| Rail to Rail |
Rail to Rail Output |
| Minimum Single Supply Voltage (V) |
2.7 |
| Number of Channels per Chip |
2 |
| Minimum PSRR (dB) |
120(Typ) |
| Typical Single Supply Voltage (V) |
3|5|9|12|15|18|24|28 |
| Maximum Single Supply Voltage (V) |
36 |
| Maximum Quiescent Current (mA) |
0.29 |
| Minimum Dual Supply Voltage (V) |
±1.35 |
| Typical Gain Bandwidth Product (MHz) |
1.2 |
| Maximum Input Offset Voltage (mV) |
1.8 |
| Typical Dual Supply Voltage (V) |
±3|±5|±9|±12|±15 |
| Maximum Input Offset Current (uA) |
0.000015 |
| Maximum Dual Supply Voltage (V) |
±18 |
| Maximum Operating Supply Voltage (V) |
±18|36 |
| Maximum Input Bias Current (uA) |
0.000015 |
| Minimum CMRR (dB) |
90 |
| Maximum Supply Voltage Range (V) |
36 to 37 |
| Minimum CMRR Range (dB) |
90 to 95 |
| Typical Voltage Gain (dB) |
130 |
| Typical Slew Rate (V/us) |
0.4 |
| Typical Input Offset Current (uA) |
0.000004 |
| Typical Settling Time (ns) |
28000 |
| Typical Output Current (mA) |
17 |
| Typical Input Noise Voltage Density (nV/rtHz) |
22 |
| Typical Input Bias Current (uA) |
0.000008 |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single|Dual |
| Typical Output Resistance (Ohm) |
900 |
| Input Offset Voltage Drift (uV/°C) |
2 |
