| Manufacturer Type |
Precision Amplifier |
| Type |
Precision Amplifier |
| Rail to Rail |
Rail to Rail Input/Output |
| Minimum Single Supply Voltage (V) |
2.7 |
| Number of Channels per Chip |
2 |
| Process Technology |
0.6 micron CMOS |
| Minimum PSRR (dB) |
87.96(Typ) |
| Typical Single Supply Voltage (V) |
5 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Output Type |
CMOS |
| Maximum Quiescent Current (mA) |
15@5.5V |
| Minimum Dual Supply Voltage (V) |
±1.35 |
| Typical Gain Bandwidth Product (MHz) |
38 |
| Maximum Input Offset Voltage (mV) |
0.5@5V |
| Typical Dual Supply Voltage (V) |
±2.5 |
| Maximum Input Offset Current (uA) |
0.00001@5.5V |
| Maximum Dual Supply Voltage (V) |
±2.75 |
| Maximum Operating Supply Voltage (V) |
±2.75|5.5 |
| Maximum Input Bias Current (uA) |
0.00001@5.5V |
| Minimum CMRR (dB) |
66 |
| Maximum Supply Voltage Range (V) |
5.5 to 6 |
| Minimum CMRR Range (dB) |
65 to 70 |
| Typical Voltage Gain (dB) |
122 |
| Typical Slew Rate (V/us) |
22@5V |
| Typical Input Offset Current (uA) |
0.0000005@5V |
| Typical Settling Time (ns) |
500 |
| Typical Output Current (mA) |
40@5V |
| Typical Input Noise Voltage Density (nV/rtHz) |
7@5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.004@5V |
| Typical Input Bias Current (uA) |
0.0000005@5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single|Dual |
