| Manufacturer Type |
General Purpose Amplifier |
| Type |
General Purpose Amplifier |
| Minimum Single Supply Voltage (V) |
2.7 |
| Number of Channels per Chip |
1 |
| Minimum PSRR (dB) |
100(Typ) |
| Typical Single Supply Voltage (V) |
5 |
| Maximum Single Supply Voltage (V) |
36 |
| Minimum Dual Supply Voltage (V) |
±1.35 |
| Typical Gain Bandwidth Product (MHz) |
1.4 |
| Maximum Input Offset Voltage (mV) |
0.75@5V |
| Typical Dual Supply Voltage (V) |
±15 |
| Maximum Input Offset Current (uA) |
0.01@5V |
| Maximum Dual Supply Voltage (V) |
±18 |
| Maximum Operating Supply Voltage (V) |
±18|36 |
| Maximum Input Bias Current (uA) |
0.04@5V |
| Minimum CMRR (dB) |
78 |
| Maximum Supply Voltage Range (V) |
36 to 37 |
| Minimum CMRR Range (dB) |
75 to 80 |
| Typical Voltage Gain (dB) |
88 |
| Typical Slew Rate (V/us) |
0.5@5V |
| Typical Settling Time (ns) |
16000 |
| Typical Input Noise Voltage Density (nV/rtHz) |
28@5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) |
0.06@5V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
70 |
| Power Supply Type |
Single|Dual |
