| Family Name |
PIC16 |
| Data Bus Width (bit) |
8 |
| Device Core |
PIC |
| Instruction Set Architecture |
RISC |
| Maximum Clock Rate (MHz) |
20 |
| Program Memory Type |
Flash |
| Program Memory Size |
3.5KB |
| RAM Size |
224B |
| Maximum Expanded Memory Size |
64KB |
| Power On Reset |
No |
| Memory Protection Unit |
No |
| Temperature Sensor |
No |
| DDR |
No |
| Memory Management Unit |
No |
| Integrated Development Environment |
Yes |
| Super Scalar |
No |
| External Bus Interface |
No |
| EEPROM |
128B |
| Direct Memory Access |
No |
| Floating Point Unit |
No |
| Bluetooth |
No |
| Wi-Fi |
No |
| Multiply Accumulate |
No |
| Internal/External Clock Type |
Internal/External |
| Touch Sensing Interface |
No |
| Maximum CPU Frequency (MHz) |
20 |
| Number of Programmable I/Os |
16 |
| Number of Timers |
3 |
| Core Architecture |
PIC |
| PWM |
1 |
| Watchdog |
1 |
| Analog Comparators |
2 |
| Interface Type |
SCI/USART |
| Programmability |
Yes |
| SPI |
0 |
| I2C |
0 |
| Process Technology |
CMOS |
| I2S |
0 |
| UART |
0 |
| USART |
1 |
| CAN |
0 |
| USB |
0 |
| Ethernet |
0 |
| Maximum Power Dissipation (mW) |
800 |
| Minimum Operating Supply Voltage (V) |
3 |
| Typical Operating Supply Voltage (V) |
3.3|5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Industrial |
| Operating Supply Voltage (V) |
3.3|5 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
