| Data Bus Width (bit) |
8 |
| Family Name |
PIC18 |
| Device Core |
PIC |
| Instruction Set Architecture |
RISC |
| Maximum Clock Rate (MHz) |
64 |
| Program Memory Type |
Flash |
| Program Memory Size |
32KB |
| RAM Size |
2048B |
| Maximum CPU Frequency (MHz) |
64 |
| Number of Programmable I/Os |
25 |
| Number of Timers |
4 |
| ADC Channels |
24 |
| ADC Resolution (bit) |
10 |
| DAC Channels |
1 |
| Core Architecture |
PIC |
| Number of ADCs |
Single |
| DAC Resolution (bit) |
5 |
| Number of DACs |
Single |
| Interface Type |
I2C/SPI/USART |
| SPI |
1 |
| I2C |
1 |
| I2S |
0 |
| UART |
0 |
| USART |
1 |
| CAN |
0 |
| USB |
0 |
| Ethernet |
0 |
| Minimum Operating Supply Voltage (V) |
2.3 |
| Typical Operating Supply Voltage (V) |
2.5|3.3|5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Industrial |
| Operating Supply Voltage (V) |
2.5|3.3|5 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
