| Data Bus Width (bit) |
8 |
| Series name |
PIC18 |
| Device Core |
PIC |
| Instruction Set Architecture |
RISC |
| Maximum Clock Rate (MHz) |
40 |
| Program Memory Type |
Flash |
| Program Memory Size |
48KB |
| RAM Size |
3936B |
| Maximum Expanded Memory Size |
2MB |
| Maximum CPU Frequency (MHz) |
40 |
| EEPROM |
1KB |
| Direct Memory Access |
no |
| Floating Point Unit |
no |
| Bluetooth |
no |
| Wi-Fi |
no |
| Multiply Accumulate |
no |
| Internal/External Clock Type |
Internal/External |
| Touch Sensing Interface |
no |
| Power On Reset |
no |
| Memory Protection Unit |
no |
| Temperature Sensor |
yes |
| DDR |
no |
| Memory Management Unit |
no |
| Integrated Development Environment |
yes |
| Super Scalar |
no |
| External Bus Interface |
no |
| Number of Programmable I/Os |
54 |
| Number of Timers |
5 |
| ADC Channels |
12 |
| ADC Resolution (bit) |
10 |
| Number of ADCs |
Single |
| Core Architecture |
PIC |
| PWM |
5 |
| Watchdog |
1 |
| Analog Comparators |
2 |
| Parallel Master Port |
no |
| Real Time Clock |
yes |
| Interface Type |
I2C/SPI/USART |
| Programmability |
yes |
| SPI |
2 |
| I2C |
2 |
| I2S |
0 |
| UART |
0 |
| USART |
2 |
| CAN |
0 |
| USB |
0 |
| Ethernet |
0 |
| Maximum Power Dissipation (mW) |
1000 |
| Minimum Operating Supply Voltage (V) |
4.2 |
| Typical Operating Supply Voltage (V) |
5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Supplier Temperature Rating |
Industrial |
| Operating Supply Voltage (V) |
5 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
