| type |
Ultra-Small Type |
| IP Rating |
IP64 |
| Peak Emission Wavelength (nm) |
855 |
| Maximum Operating Temperature (°C) |
55 |
| Minimum Operating Temperature (°C) |
-25 |
| Temperature Flag |
Opr |
| Maximum Sensing Distance (m) |
0.006 |
| Light Source |
Infrared |
| Maximum Operating Supply Voltage |
24VDC |
| Minimum Operating Supply Voltage |
5VDC |
| Output Type |
NPN Open Collector |
| Maximum Response Time (ms) |
0.08 |
| Maximum Ambient Illumination (lux) |
1000 |
| Housing Material |
Polybutylene Terephthalate |
| Shock Rating(G) |
1500 |
| Terminal Type |
Cable |
| Switching Mode |
Light ON/Dark ON |
| Maximum Storage Temperature (°C) |
80 |
| Minimum Storage Temperature (°C) |
-30 |
