| Family Name |
RX |
| Data Bus Width (bit) |
32 |
| Device Core |
RX |
| Instruction Set Architecture |
CISC |
| Maximum Clock Rate (MHz) |
100 |
| Program Memory Type |
Flash |
| Program Memory Size |
512KB |
| RAM Size |
128KB |
| Maximum Expanded Memory Size |
4GB |
| Maximum CPU Frequency (MHz) |
100 |
| Bluetooth |
No |
| Wi-Fi |
No |
| Data Memory Size |
32KB |
| Memory Protection Unit |
No |
| DDR |
No |
| Memory Management Unit |
No |
| Integrated Development Environment |
No |
| External Bus Interface |
No |
| GPIO |
111 |
| Number of Timers |
7 |
| ADC Channels |
8/21 |
| DAC Channels |
2 |
| ADC Resolution (bit) |
10/12 |
| Core Architecture |
RX |
| Number of ADCs |
2 |
| Number of DACs |
1 |
| DAC Resolution (bit) |
10 |
| PWM |
1 |
| Watchdog |
2 |
| Parallel Master Port |
No |
| Real Time Clock |
Yes |
| Special Features |
CAN Controller |
| Interface Type |
CAN/I2C/SCI/SPI/USB |
| Timers Resolution (bit) |
8/16 |
| Programmability |
Yes |
| SPI |
3 |
| I2C |
4 |
| I2S |
0 |
| UART |
0 |
| USART |
0 |
| CAN |
2 |
| USB |
2 |
| Ethernet |
0 |
| Maximum Power Dissipation (mW) |
380 |
| Minimum Operating Supply Voltage (V) |
2.7 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Operating Supply Voltage (V) |
3.3 |
| Maximum Storage Temperature (°C) |
125 |
| Minimum Storage Temperature (°C) |
-55 |
