| Channel Type |
P |
| Channel Mode |
Enhancement |
| Configuration |
Single |
| Maximum Drain Source Voltage (V) |
20 |
| Maximum Absolute Continuous Drain Current (A) |
0.1 |
| Maximum Continuous Drain Current (A) |
0.1 |
| Maximum Gate Source Voltage (V) |
±10 |
| Maximum Drain Source Resistance (mOhm) |
3800@4.5V |
| Maximum Power Dissipation (mW) |
100 |
| Category |
Small Signal |
| Typical Input Capacitance @ Vds (pF) |
15@10V |
| Typical Turn-On Delay Time (ns) |
46 |
| Typical Turn-Off Delay Time (ns) |
325 |
| Typical Fall Time (ns) |
137 |
| Typical Rise Time (ns) |
62 |
| Maximum Gate Source Leakage Current (nA) |
10000 |
| Maximum Gate Threshold Voltage (V) |
1 |
| Maximum IDSS (uA) |
1 |
| Number of Elements per Chip |
1 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
150 |
