COUNTRY OF ORIGIN
|
Thailand
|
|
PARAMETRIC INFO
|
| Density (bit) |
128M |
| Timing Type |
Synchronous |
| Data Rate Architecture |
DDR |
| Maximum Clock Rate (MHz) |
200 |
| Maximum Access Time (ns) |
35(Min) |
| Typical Operating Supply Voltage (V) |
1.8 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
105 |
| Supplier Temperature Grade |
Industrial Plus |
| Density in Bits (bit) |
134217728 |
| Number of Bits per Word (bit) |
8 |
| Number of Ports |
1 |
| Number of Words |
16M |
| Maximum Operating Supply Current (mA) |
60 |
| Address Bus Width (bit) |
32 |
| Minimum Operating Supply Voltage (V) |
1.7 |
| Maximum Operating Supply Voltage (V) |
2 |
|
|
PACKAGE INFO
|
| Supplier Package |
BGA |
| Basic Package Type |
Ball Grid Array |
| Pin Count |
24 |
| Lead Shape |
Ball |
| PCB |
24 |
| Tab |
N/R |
| Pin Pitch (mm) |
1 |
| Package Length (mm) |
8 |
| Package Width (mm) |
6 |
| Package Height (mm) |
1(Max) - 0.2(Min) |
| Package Diameter (mm) |
N/R |
| Seated Plane Height (mm) |
1(Max) |
| Mounting |
Surface Mount |
| Package Material |
Plastic |
| Package Description |
Plastic Ball Grid Array |
| Package Family Name |
BGA |
| Package Outline |
Link to Datasheet |
|
|
MANUFACTURING INFO
|
|
|
PACKAGING INFO
|
| Packaging |
Tray |
| Packaging Document |
Link to Datasheet |
|
|
