| Family Name |
XC2000 |
| Data Bus Width (bit) |
16|32 |
| Device Core |
C166SV2 |
| Instruction Set Architecture |
CISC|DSP|RISC |
| Maximum Clock Rate (MHz) |
80 |
| Program Memory Type |
Flash |
| Program Memory Size |
320KB |
| RAM Size |
42KB |
| Maximum Expanded Memory Size |
16MB |
| Maximum CPU Frequency (MHz) |
80 |
| GPIO |
76 |
| Number of Timers |
5 |
| ADC Channels |
5/5 |
| ADC Resolution (bit) |
10/10 |
| Core Architecture |
C166 |
| Number of ADCs |
2 |
| PWM |
2 |
| Watchdog |
1 |
| Interface Type |
CAN/I2C/SPI/UART |
| Programmability |
Yes |
| SPI |
1 |
| I2C |
1 |
| I2S |
0 |
| UART |
1 |
| USART |
0 |
| CAN |
3 |
| USB |
0 |
| Ethernet |
0 |
| Maximum Power Dissipation (mW) |
800 |
| Minimum Operating Supply Voltage (V) |
3 |
| Typical Operating Supply Voltage (V) |
3.3|5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Temperature Flag |
Opr |
| Operating Supply Voltage (V) |
3.3|5 |
