• Proprietary S15H ferrite material
|
• High permeability
|
• High impedance
|
• Space saving due to high permeability material
|
• Operating temperature range from −40°C to +120°C
|
• UL 94 V–0 flame retardant rated base and cap
|
|
| CATALOG |
SCR25B-150-1R4A024J COUNTRY OF ORIGIN
|
SCR25B-150-1R4A024J PARAMETRIC INFO
|
SCR25B-150-1R4A024J PACKAGE INFO
|
SCR25B-150-1R4A024J PACKAGING INFO
|
SCR25B-150-1R4A024J APPLICATIONS
|
|
COUNTRY OF ORIGIN
|
United States of America
|
|
PARAMETRIC INFO
|
| Type |
Power Line |
| Number of Lines |
2 |
| Configuration |
Dual |
| Inductance (H) |
2400u(Min) |
| Test Frequency (Hz) |
10k |
| Maximum DC Current (A) |
15 |
| Maximum DC Resistance (Ohm) |
0.0115 |
| Minimum Insulation Resistance (Ohm) |
>100M |
| Voltage Rating |
250VAC|250VDC |
| Withstand Voltage |
2.4kVAC |
| Maximum Operating Temperature (°C) |
120 |
| Minimum Operating Temperature (°C) |
-40 |
|
|
PACKAGE INFO
|
| Mounting |
Through Hole |
| Case Size |
N/R |
|
|
PACKAGING INFO
|
| Packaging |
Tray |
| Packaging Document |
Link to Datasheet |
|
|
APPLICATIONS
|
• Audio-visual equipment
|
• Home appliances
|
• Power supplies
|
| |
