| CATALOG |
| SCZH-002T-P0.5 COUNTRY OF ORIGIN |
| SCZH-002T-P0.5 PARAMETRIC INFO |
| SCZH-002T-P0.5 PACKAGE INFO |
| SCZH-002T-P0.5 MANUFACTURING INFO |
| SCZH-002T-P0.5 PACKAGING INFO |
|
| COUNTRY OF ORIGIN |
| China |
|
| PARAMETRIC INFO |
| Series Name |
RIZ |
| Connector Type |
Connector Headers and PCB Receptacles |
| Gender |
SKT |
| Termination Method |
Crimp |
| Contact Type |
Signal |
| Maximum Voltage Rating |
50VDC|50VAC |
| Maximum Current Rating (A) |
1 |
| Maximum Contact Resistance (mOhm) |
60 |
| Contact Material |
Copper Alloy |
| Contact Plating |
Tin |
| Shielded |
No |
| Wire Size (AWG) |
26-28 |
| Operating Temperature (°C) |
-25 to 85 |
| Minimum Operating Temperature (°C) |
-25 |
| Maximum Operating Temperature (°C) |
85 |
|
| |
| PACKAGE INFO |
| Body Orientation |
Straight |
| Mounting |
Cable Mount |
| Product Length (mm) |
4.05 |
| Product Depth (mm) |
1.1 |
| Product Height (mm) |
N/A |
|
| |
| MANUFACTURING INFO |
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
|
| |
| PACKAGING INFO |
|
|
|
