• Wide 7.5-V to 100-V input range
|
• Integrated 100-V high-side and low-side switches
|
• No schottky required
|
• Constant on-time control
|
• No loop compensation required
|
| • Ultra-fast transient response |
| • Nearly constant operating frequency
|
| • Intelligent peak current limit |
| • Adjustable output voltage from 1.225 V |
| • Precision 2% feedback reference |
| • Frequency adjustable to 1 MHz |
| • Adjustable undervoltage lockout (UVLO)
|
| • Remote shutdown |
|
| CATALOG |
SG3525AP013TR COUNTRY OF ORIGIN
|
SG3525AP013TR PARAMETRIC INFO
|
SG3525AP013TR PACKAGE INFO
|
SG3525AP013TR MANUFACTURING INFO
|
SG3525AP013TR PACKAGING INFO
|
SG3525AP013TR ECAD MODELS
|
|
COUNTRY OF ORIGIN
|
China
|
|
PARAMETRIC INFO
|
| Control Method |
Voltage |
| Number of PWM Outputs |
1 |
| Maximum Duty Cycle (%) |
49(Typ) |
| Switching Frequency (kHz) |
400(Min) |
| Output Current (mA) |
500(Max) |
| Minimum Operating Temperature (°C) |
0 |
| Maximum Operating Temperature (°C) |
70 |
| Rise Time (ns) |
100 |
| On/Off Pin |
No |
| Adjustable Output |
No |
| Synchronous Pin |
Yes |
| Fall Time (ns) |
50 |
| Operating Supply Voltage (V) |
8 to 35 |
| Minimum Operating Supply Voltage (V) |
8 |
| Maximum Supply Current (mA) |
20 |
| Maximum Operating Supply Voltage (V) |
35 |
| Maximum Power Dissipation (mW) |
1000 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Type |
Voltage Mode PWM Controller |
|
|
PACKAGE INFO
|
| Supplier Package |
SO N |
| Basic Package Type |
Lead-Frame SMT |
| Pin Count |
16 |
| Lead Shape |
Gull-wing |
| PCB |
16 |
| Tab |
N/R |
| Pin Pitch (mm) |
1.27 |
| Package Length (mm) |
10(Max) |
| Package Width (mm) |
4(Max) |
| Package Height (mm) |
1.6(Max) |
| Package Diameter (mm) |
N/R |
| Package Overall Length (mm) |
10(Max) |
| Package Overall Width (mm) |
6.2(Max) |
| Package Overall Height (mm) |
1.75(Max) |
| Seated Plane Height (mm) |
1.75(Max) |
| Mounting |
Surface Mount |
| Package Weight (g) |
N/A |
| Package Material |
Plastic |
| Package Description |
Small Outline IC Narrow Body |
| Package Family Name |
SO |
| Package Outline |
Link to Datasheet |
|
|
MANUFACTURING INFO
|
| MSL |
3 |
| Maximum Reflow Temperature (°C) |
260 |
| Number of Reflow Cycle |
3 |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
Au |
| Under Plating Material |
Pd over Ni |
| Terminal Base Material |
Cu Alloy |
| Shelf Life Period |
2 Years |
| Number of Wave Cycles |
N/R |
|
|
PACKAGING INFO
|
|
|
|
ECAD MODELS
|
|
|
