| Manufacturer Type |
Cascadable Amplifier |
| Number of Channels per Chip |
1 |
| Maximum Input VSWR |
1.8(Typ) |
| Maximum Output VSWR |
2.2(Typ) |
| Typical Power Gain (dB) |
9.5@6000MHz |
| Typical Noise Figure (dB) |
3.4@2400MHz |
| Typical Output Intercept Point (dBm) |
6.3@2400MHz |
| Maximum Reverse Isolation (dB) |
28.5(Typ)@6000MHz |
| Maximum Operating Frequency (MHz) |
6000 |
| Typical Output Power (dBm) |
4.6@2400MHz |
| Typical Output Power Range (dBm) |
4 to 10 |
| Maximum Input Return Loss (dB) |
17.8(Typ)@2400MHz |
| Power Supply Type |
Single |
| Minimum Single Supply Voltage (V) |
4.2 |
| Typical Single Supply Voltage (V) |
4.6 |
| Maximum Single Supply Voltage (V) |
5 |
| Maximum Operating Supply Voltage (V) |
5 |
| Maximum Supply Current (mA) |
14 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
