| Channel Type |
P |
| Channel Mode |
Enhancement |
| Configuration |
Single Quad Drain Triple Source |
| Maximum Drain Source Voltage (V) |
200 |
| Maximum Continuous Drain Current (A) |
1.2 |
| Maximum Gate Source Voltage (V) |
±20 |
| Maximum Drain Source Resistance (mOhm) |
1050@10V |
| Typical Gate Charge @ Vgs (nC) |
16.2@10V|10.6@6V |
| Typical Gate Charge @ 10V (nC) |
16.2 |
| Maximum Power Dissipation (mW) |
3700 |
| Process Technology |
TrenchFET |
| Category |
Power MOSFET |
| Typical Input Capacitance @ Vds (pF) |
666@50V |
| Typical Turn-On Delay Time (ns) |
9|16 |
| Typical Turn-Off Delay Time (ns) |
25|27 |
| Typical Fall Time (ns) |
12|16 |
| Typical Rise Time (ns) |
16|11 |
| Number of Elements per Chip |
1 |
| Minimum Storage Temperature (°C) |
-50 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-50 |
| Maximum Operating Temperature (°C) |
150 |
