| Number of Channels per Chip |
6 |
| Type |
General Purpose |
| Isolated Power |
No |
| Output Type |
CMOS |
| Minimum Isolation Voltage (Vrms) |
2500 |
| Maximum Power Dissipation (mW) |
415 |
| Minimum Pulse Width (ns) |
5 |
| Maximum Pulse Width Distortion (ns) |
4.5 |
| Minimum Common Mode Rejection (kV/us) |
50 |
| Maximum Working Insulation Voltage |
630Vp |
| Maximum Fall Time (ns) |
4 |
| Maximum Rise Time (ns) |
4 |
| Maximum Propagation Delay Time (tPHL) (ns) |
14 |
| Maximum Propagation Delay Time (tPLH) (ns) |
13 |
| Maximum Propagation Delay Skew (ns) |
4.5 |
| Maximum Data Rate |
150Mbps |
| Minimum Operating Supply Voltage (V) |
2.375 |
| Typical Operating Supply Voltage (V) |
2.5|3.3|5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Automotive |
| Maximum Output Current Drive (mA) |
10 |
| Maximum Quiescent Supply Current (mA) |
10.5/8.4 |
| Coupling Type |
Capacitive Coupling |
| Forward/Reverse Channels |
4/2 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
