| Logic Family |
LS |
| Logic Function |
Decoder/Driver |
| Process Technology |
Bipolar |
| Demultiplexing Capability |
1-of-10 |
| Number of Elements per Chip |
1 |
| Number of Element Inputs |
4 |
| Number of Element Outputs |
10 |
| Polarity |
Inverting |
| Maximum High Level Output Current (mA) |
-0.25 |
| Maximum Low Level Output Current (mA) |
80 |
| Output Type |
Open Collector |
| Number of Input Enables per Element |
0 |
| Number of Output Enables per Element |
0 |
| Maximum Propagation Delay Time @ Maximum CL (ns) |
50@5V |
| Propagation Delay Test Condition (pF) |
45 |
| Absolute Propagation Delay Time (ns) |
50 |
| Minimum Operating Temperature (°C) |
0 |
| Maximum Operating Temperature (°C) |
70 |
| Supplier Temperature Grade |
Commercial |
| Minimum Operating Supply Voltage (V) |
4.75 |
| Typical Operating Supply Voltage (V) |
5 |
| Maximum Operating Supply Voltage (V) |
5.25 |
| Maximum Quiescent Current (mA) |
7(Typ) |
