| Logic Family |
LVC |
| Logic Function |
AND-OR |
| Number of Element Inputs |
3-IN |
| Number of Element Outputs |
1 |
| Number of Elements per Chip |
1 |
| Number of Output Enables per Element |
0 |
| Number of Selection Inputs per Element |
0 |
| Output Type |
Push-Pull |
| Minimum Operating Supply Voltage (V) |
1.65 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Typical Operating Supply Voltage (V) |
1.8|2.5|3.3|5 |
| Maximum High Level Output Current (mA) |
-32 |
| Maximum Low Level Output Current (mA) |
32 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Commercial |
| Maximum Propagation Delay Time @ Maximum CL (ns) |
5.9@3.3V|4@5V |
| Absolute Propagation Delay Time (ns) |
17.5 |
| Propagation Delay Test Condition (pF) |
50 |
| Maximum Quiescent Current (uA) |
10 |
