| Function |
Line Transceiver |
| Number of Transceivers |
1 |
| Number of Transmitters |
5 |
| Number of Receivers |
3 |
| Data Transmission Topology |
Point-to-Point |
| Transmitter Signal Type |
Single-Ended |
| Receiver Signal Type |
Single-Ended |
| Transmitter Communication Type |
RS-232 |
| Charge Pump |
Yes |
| Number of External Capacitors |
4 |
| External Capacitor Capacitance (uF) |
0.1 |
| Power Down Mode |
Shutdown |
| Typical Shutdown Current (uA) |
1 |
| Channel Operating Mode |
Full Duplex |
| Receiver Communication Type |
RS-232 |
| Input Logic Level |
TTL|CMOS |
| Output Logic Level |
TTL|CMOS |
| Interface Standards |
EIA/TIA-232|EIA/TIA-232-F|EIA/TIA-562|RS-232 |
| Number of Transmitter Enables |
2 |
| Number of Receiver Enables |
0 |
| Number of Drivers per Line |
1 |
| Number of Receivers per Line |
1 |
| Data Rate |
250Kbps(Min) |
| Driving Mode |
3-State |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Supplier Temperature Grade |
Extended |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
| Power Supply Type |
Single |
| Typical Single Supply Voltage (V) |
3.3|5 |
| Minimum Single Supply Voltage (V) |
3 |
| Maximum Single Supply Voltage (V) |
5.5 |
| Maximum Supply Current (mA) |
1 |
