• Height of 3.0 mm max.
|
• Current rating up to 3.1 A
|
• RoHS compliant*
|
|
| CATALOG |
SRR4028-331Y COUNTRY OF ORIGIN
|
SRR4028-331Y PARAMETRIC INFO
|
SRR4028-331Y PACKAGE INFO
|
SRR4028-331Y MANUFACTURING INFO
|
SRR4028-331Y PACKAGING INFO
|
SRR4028-331Y ECAD MODELS
|
SRR4028-331Y APPLICATIONS
|
|
COUNTRY OF ORIGIN
|
Malaysia
|
China
|
|
PARAMETRIC INFO
|
| Type |
Power |
| Technology |
Wirewound |
| Protection Style |
Shielded |
| Core Material |
Ferrite |
| Inductance (H) |
330u |
| Tolerance |
30% |
| Inductance Test Frequency (Hz) |
100K |
| Maximum DC Current (A) |
0.3 |
| Maximum Saturation Current (A) |
0.17(Typ) |
| Maximum DC Resistance (Ohm) |
1.7 |
| Inductance Decrease Percentage @ Isat (%) |
35 |
| Minimum Quality Factor |
16.48 |
| Quality Test Frequency (Hz) |
796K |
| Minimum Self Resonant Frequency (Hz) |
5M(Typ) |
| Maximum Operating Temperature (°C) |
125 |
| Minimum Operating Temperature (°C) |
-40 |
| Operating Temperature (°C) |
-40 to 125 |
|
|
PACKAGE INFO
|
| Case Size |
N/A |
| Maximum Product Length (mm) |
5 |
| Maximum Product Depth (mm) |
5 |
| Maximum Product Height (mm) |
3 |
| Maximum Product Diameter (mm) |
N/R |
| Number of Terminals |
2 |
| Product Weight (g) |
N/A |
| Mounting |
Surface Mount |
|
|
MANUFACTURING INFO
|
| MSL |
1 |
| Maximum Reflow Temperature (°C) |
260 |
| Reflow Solder Time (Sec) |
10 |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
Sn |
| Under Plating Material |
Ni |
| Terminal Base Material |
Ag |
|
|
PACKAGING INFO
|
|
|
|
ECAD MODELS
|
|
|
APPLICATIONS
|
• Input/output of DC/DC converters
|
• Power supplies for:• Portable communication equipment• Camcorders• LCD TVs
|
|
