| Type |
PNP |
| Configuration |
Single |
| Maximum Collector-Emitter Voltage (V) |
60 |
| Maximum Collector-Base Voltage (V) |
60 |
| Maximum Base-Emitter Voltage (V) |
5 |
| Maximum DC Collector Current (A) |
0.6 |
| Maximum Power Dissipation (mW) |
350 |
| Maximum Emitter Cut-Off Current (nA) |
100 |
| Typical Input Capacitance (pF) |
30 |
| Typical Output Capacitance (pF) |
8 |
| Maximum Storage Time (ns) |
80 |
| Maximum Fall Time (ns) |
30 |
| Maximum Turn-Off Time (ns) |
110 |
| Maximum Delay Time (ns) |
10 |
| Maximum Rise Time (ns) |
40 |
| Maximum Collector Cut-Off Current (nA) |
100 |
| Maximum Collector-Emitter Saturation Voltage (V) |
0.4@15mA@150mA|1.6@50mA@500mA |
| Maximum Base-Emitter Saturation Voltage (V) |
1.3@15mA@150mA|2.6@50mA@500mA |
| Category |
Bipolar Small Signal |
| Number of Elements per Chip |
1 |
| Maximum Turn-On Time (ns) |
50 |
| Maximum Transition Frequency (MHz) |
200(Min) |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
150 |
| Supplier Temperature Grade |
Automotive |
