| Family Name |
STM32F |
| Data Bus Width (bit) |
32 |
| Device Core |
ARM Cortex M4 |
| Instruction Set Architecture |
RISC |
| Maximum Clock Rate (MHz) |
100 |
| Program Memory Type |
Flash |
| Program Memory Size |
1.5MB |
| RAM Size |
320KB |
| Maximum CPU Frequency (MHz) |
100 |
| Number of Programmable I/Os |
81 |
| Number of Timers |
15 |
| ADC Channels |
16 |
| ADC Resolution (bit) |
12 |
| DAC Channels |
2 |
| Core Architecture |
ARM |
| Number of ADCs |
1 |
| DAC Resolution (bit) |
12 |
| Number of DACs |
1 |
| PWM |
2 |
| Watchdog |
2 |
| Parallel Master Port |
No |
| Real Time Clock |
Yes |
| Special Features |
CAN Controller |
| Interface Type |
CAN/I2C/I2S/SPI/UART/USART/USB |
| Programmability |
Yes |
| SPI |
5 |
| I2C |
4 |
| I2S |
5 |
| UART |
3 |
| USART |
4 |
| CAN |
3 |
| USB |
1 |
| Ethernet |
0 |
| Maximum Power Dissipation (mW) |
465 |
| Minimum Operating Supply Voltage (V) |
1.7 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Industrial |
| Operating Supply Voltage (V) |
3.3 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
