| Data Bus Width (bit) |
8 |
| Family Name |
STM8S |
| Device Core |
STM8 |
| Instruction Set Architecture |
CISC |
| Maximum Clock Rate (MHz) |
16 |
| Program Memory Type |
Flash |
| Program Memory Size |
16KB |
| RAM Size |
2KB |
| Maximum Expanded Memory Size |
16MB |
| Data Memory Size |
1KB |
| Maximum CPU Frequency (MHz) |
16 |
| Number of Programmable I/Os |
38 |
| Number of Timers |
5 |
| ADC Channels |
10 |
| ADC Resolution (bit) |
10 |
| Core Architecture |
STM8 |
| Number of ADCs |
Single |
| PWM |
2 |
| Watchdog |
2 |
| Interface Type |
I2C/SPI/UART |
| Programmability |
Yes |
| SPI |
1 |
| I2C |
1 |
| I2S |
0 |
| UART |
1 |
| USART |
0 |
| CAN |
0 |
| USB |
0 |
| Ethernet |
0 |
| Maximum Power Dissipation (mW) |
443 |
| Minimum Operating Supply Voltage (V) |
2.95 |
| Typical Operating Supply Voltage (V) |
3.3|5 |
| Maximum Operating Supply Voltage (V) |
5.5 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Temperature Flag |
Opr |
| Operating Supply Voltage (V) |
3.3|5 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
