| Amplifier Type |
Class-SB |
| Function |
Speaker |
| Input Signal Type |
Single |
| Output Signal Type |
Differential |
| Output Type |
4-Channel Stereo |
| Power Supply Type |
Single |
| Minimum Single Supply Voltage (V) |
6 |
| Typical Single Supply Voltage (V) |
9|12|15 |
| Maximum Single Supply Voltage (V) |
18 |
| Maximum Input Offset Voltage (mV) |
80 |
| Maximum Load Resistance (Ohm) |
4 |
| Maximum Output Current (mA) |
8000 |
| Typical Output Power (W) |
44 |
| Maximum Output Power (W) |
68 |
| Typical Output Power x Channels @ Load (W) |
44x4@2Ohm |
| Maximum Output Power x Channels @ Load (W) |
68x4@2Ohm |
| Maximum Power Dissipation (mW) |
85000 |
| Typical Quiescent Current (mA) |
155@14.4V |
| Maximum Quiescent Current (mA) |
250@14.4V |
| Minimum CMRR (dB) |
70(Typ) |
| Total Harmonic Distortion Noise |
0.015%@4Ohm@10W |
| Typical Voltage Gain (dB) |
26 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
105 |
| Minimum Storage Temperature (°C) |
-55 |
| Maximum Storage Temperature (°C) |
150 |
