• Supports all major AM and FM global radio standards
|
• PLL synthesizer with integrated VCO
|
• PACS (variable IF bandwidth function) (except TEF6601 )
|
• Stereo decoder
|
• Advanced weak signal processing (soft mute, HCC, SNC)
|
• AM / FM noise blanker (TEF6601 - FM noise blanker only)
|
• Signal quality detection
|
|
| CATALOG |
TEF6606T/V5,518 COUNTRY OF ORIGIN
|
TEF6606T/V5,518 PARAMETRIC INFO
|
TEF6606T/V5,518 PACKAGE INFO
|
TEF6606T/V5,518 MANUFACTURING INFO
|
TEF6606T/V5,518 PACKAGING INFO
|
TEF6606T/V5,518 APPLICATIONS
|
|
COUNTRY OF ORIGIN
|
Thailand
|
|
PARAMETRIC INFO
|
|
|
|
PACKAGE INFO
|
| Supplier Package |
SO |
| Basic Package Type |
Lead-Frame SMT |
| Pin Count |
32 |
| Lead Shape |
Gull-wing |
| PCB |
32 |
| Tab |
N/R |
| Pin Pitch (mm) |
1.27 |
| Package Length (mm) |
20.7(Max) |
| Package Width (mm) |
7.6(Max) |
| Package Height (mm) |
2.45(Max) |
| Package Diameter (mm) |
N/R |
| Package Overall Length (mm) |
20.7(Max) |
| Package Overall Width (mm) |
10.65(Max) |
| Package Overall Height (mm) |
2.65(Max) |
| Seated Plane Height (mm) |
2.65(Max) |
| Mounting |
Surface Mount |
| Package Material |
Plastic |
| Package Description |
Small Outline IC |
| Package Family Name |
SO |
| Jedec |
MO-119 |
| Package Outline |
Link to Datasheet |
|
|
MANUFACTURING INFO
|
| MSL |
3 |
| Maximum Reflow Temperature (°C) |
250 |
| Reflow Solder Time (Sec) |
30 |
| Number of Reflow Cycle |
3 |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
260 |
| Wave Solder Time (Sec) |
5 |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
Au |
| Under Plating Material |
Pd over Ni |
| Terminal Base Material |
Cu Alloy |
|
|
PACKAGING INFO
|
| Packaging |
Tape and Reel |
| Quantity Of Packaging |
1000 |
|
|
APPLICATIONS
|
• Car entertainment systems
|
• Multi-tuner car radios
|
• Single-tuner car radios
|
• Car audio systems
|
• Home entertainment systems
|
|
