| Tradename |
Tiva™ |
| Family Name |
Tiva C |
| Data Bus Width (bit) |
32 |
| Device Core |
ARM Cortex M4F |
| Maximum Clock Rate (MHz) |
120 |
| Program Memory Type |
Flash |
| Program Memory Size |
1MB |
| RAM Size |
256KB |
| Maximum CPU Frequency (MHz) |
120 |
| Hardware Acceleration |
FPU |
| Trace Hardware |
JTAG |
| Encryption Standard |
AES |
| DMA Channels |
32 |
| EEPROM |
6KB |
| Direct Memory Access |
Yes |
| Floating Point Unit |
Yes |
| Bluetooth |
No |
| Wi-Fi |
No |
| Multiply Accumulate |
Yes |
| Input Capture Channels |
12 |
| Output Compare Channels |
12 |
| Internal/External Clock Type |
Internal/External |
| Touch Sensing Interface |
No |
| Power On Reset |
No |
| Memory Protection Unit |
Yes |
| Temperature Sensor |
Yes |
| DDR |
No |
| Memory Management Unit |
No |
| Integrated Development Environment |
No |
| Super Scalar |
No |
| External Bus Interface |
No |
| Ethernet Interface Type |
MII/RMII |
| Ethernet Speed |
10Mbps/100Mbps |
| Number of Programmable I/Os |
15 |
| Number of Timers |
8 |
| ADC Channels |
20 |
| ADC Resolution (bit) |
12/12 |
| Core Architecture |
ARM |
| Number of ADCs |
Single |
| PWM |
8 |
| Watchdog |
2 |
| Analog Comparators |
3 |
| Parallel Master Port |
No |
| Real Time Clock |
Yes |
| Special Features |
CAN Controller |
| Interface Type |
CAN/Ethernet/I2C/UART/USB |
| Programmability |
Yes |
| SPI |
0 |
| I2C |
10 |
| I2S |
0 |
| UART |
8 |
| USART |
0 |
| CAN |
2 |
| USB |
1 |
| Ethernet |
1 |
| Minimum Operating Supply Voltage (V) |
2.97 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Maximum Operating Supply Voltage (V) |
3.63 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
105 |
| Temperature Flag |
Opr |
| Operating Supply Voltage (V) |
3.3 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
