• Rated dissipation P70 up to 0.52 W for size 1206
|
• AEC-Q200 qualified
|
• Single lot date code (optional)
|
• Permissible film temperature up to 175 °C
|
• Superior temperature cycling robustness
|
• Excellent overall stability at different environmental conditions
|
• Superior moisture resistivity, |ΔR/R| < 0.1 % (85 °C; 85 % RH; 1000 h)
|
• Superior sulfur resistance verified according to ASTM B 809 and ANSI/EIA-977
|
• Material categorization: for definitions of compliance please see www.vishay.com/doc?99912
|
|
| CATALOG |
TNPW06038K56BEEA COUNTRY OF ORIGIN
|
TNPW06038K56BEEA PARAMETRIC INFO
|
TNPW06038K56BEEA PACKAGE INFO
|
TNPW06038K56BEEA MANUFACTURING INFO
|
TNPW06038K56BEEA PACKAGING INFO
|
TNPW06038K56BEEA APPLICATIONS
|
|
COUNTRY OF ORIGIN
|
China
|
Germany
|
Israel
|
|
PARAMETRIC INFO
|
| Resistance Value (Ohm) |
8.56K |
| Temperature Coefficient (ppm/°C) |
±25 |
| Power Rating (W) |
0.11 |
| High Power Rating (W) |
0.21 |
| Maximum Voltage Rating (V) |
100 |
| Tolerance |
0.1% |
| Negative Resistance Tolerance (%) |
-0.1 |
| Positive Resistance Tolerance (%) |
0.1 |
| Technology |
Thin Film |
| Package Shape |
Rectangular |
| Case Style |
Conformal Coated |
| Operating Temperature (°C) |
-55 to 175 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
175 |
| Temperature Range @ Derated Power (°C) |
70 to 175 |
| Current Sensing |
No |
| Fail Safe Fusible Resistor |
No |
| Anti-Surge |
No |
| Anti-Sulfurated |
Yes |
|
|
PACKAGE INFO
|
| Case Size |
0603 |
| Package/Case |
0603 |
| Mounting |
Surface Mount |
| Package Type |
SMD |
| Termination Style |
Pad |
| Product Length (mm) |
1.55 |
| Product Depth (mm) |
0.85 |
| Product Height (mm) |
0.45 |
| Product Diameter (mm) |
N/R |
| Diameter Tolerance (mm) |
N/R |
| Product Weight (g) |
0.002 |
| Terminal Pitch (mm) |
N/R |
| Number of Terminals |
2 |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
260 |
| Reflow Solder Time (Sec) |
40 |
| Number of Reflow Cycle |
3 |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
260 |
| Wave Solder Time (Sec) |
10 |
| Wave Temp. Source |
Link to Datasheet |
| Lead Finish(Plating) |
Matte Sn |
| Under Plating Material |
Ni |
| Terminal Base Material |
Ag|AgPd |
|
|
PACKAGING INFO
|
| Packaging Suffix |
EA |
| Packaging |
Tape and Reel |
| Quantity Of Packaging |
5000 |
| Reel Diameter (in) |
7 |
| Tape Pitch (mm) |
4 |
| Tape Width (mm) |
8 |
| Packaging Document |
Link to Datasheet |
| Tape Material |
Paper |
|
| |
| APPLICATIONS |
| • Automotive |
| • Industrial equipment with enhanced requirements |
| • Test and measuring equipment |
| • Medical equipment |
| |
