TNY180PN COUNTRY OF ORIGIN
|
TNY180PN PARAMETRIC INFO
|
TNY180PN PACKAGE INFO
|
TNY180PN APPLICATIONS
|
|
COUNTRY OF ORIGIN
|
China
|
|
PARAMETRIC INFO
|
| Topology |
Flyback |
| Soft Start Option |
No |
| Maximum Switching Frequency (kHz) |
132 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
150 |
|
|
PACKAGE INFO
|
| Supplier Package |
PDIP-C |
| Pin Count |
7 |
| PCB |
7 |
| Tab |
N/R |
| Pin Pitch (mm) |
2.54 |
| Package Length (mm) |
9.83(Max) |
| Package Width (mm) |
6.6(Max) |
| Package Height (mm) |
3.68(Max) |
| Package Diameter (mm) |
N/R |
| Seated Plane Height (mm) |
3.56(Min) |
| Mounting |
Through Hole |
| Package Material |
Plastic |
| Package Family Name |
DIP |
| Package Outline |
Link to Datasheet |
|
|
APPLICATIONS
|
• Chargers/adapters for cell/cordless phones, PDAs, digital cameras,MP3/portable audio, shavers, etc.
|
• DVD/PVR and other low power set top decoders
|
• Supplies for appliances, industrial systems, metering, etc.
|
| |
